However, if you were to mix output enabling with the strobing of data on PORTD, you could make it appear that all three sets of output devices are used with the use of PORTD only - but uniquely controlling each latch very quickly one after the other

Not that it is required to do so, but if all 3 latches above are disabled for output by pin RA3 being HIGH, then the eight data pins of PORTD are available for use for anything else.

PORTD pins RD0 to RD7 - used for driving the eight LEDS.

PORTD pins RD4 to RD7 - used for driving the stepper motor pins.

PORTD pins RD0 to RD3 - used for selecting each of the four 7 segment display units.

#Pickit 3 development board plus#

PORTD pins RD0 to RD7 - used for sinking the current of one segment in ecah of the four 7 segment display units, plus its decimal point.

The four 7 segment display units, eight LEDs and four Stepper motor pins are powered with the use of three 74HC573 "One way latches" which are all connected to the PORTD bus as follows and all three latches are Output enabled using the same pin RA3:.

If you look at the schematic, the data pins of USB connection are not connected.

via a USB (printer cable type) connector - N.B.

There is no power supply regulator onboard - a regulated 5v supply must be used)

There are 2 ways to supply regulated 5V to this dev board.

"DS18B20 temperature sensor" (or any 1-wire sensor) not supplied - You need to purchase this separately and insert the wires into the U10 connector.

The MPLAB PICkit 3 allows debugging and programming of PIC and dsPIC ® Flash microcontrollers at a most affordable price point. It should be used for development purposes only. If you don't have this programmer, you cannot load anything into the pic The PICkit 3 in-circuit debugger/programmer is not a production programmer.

"Pickit 3" programmer not supplied - You need to purchase this separately.

#Pickit 3 development board software#

You will need to obtain the following so you can use the associated software The following 6 items are not normally supplied with the development board.The original programs are in folder "BK300_original_code" and are as follows Press "Make and Program" to program the PIC using a Pickit 3 programmer.Add the appropriate "main_xx_?.c" file (that you want to use) into the "Source Files" section.The board features all the necessary hardware (such as power supply, user interface, communications, and I/O connectivity) to begin developing and debugging a complete.

#Pickit 3 development board code#

You could just create it from scratch and copy the code Micron - Offering PICkit3 PIC KIT3 Debugger Programmer Emulator Controller Development Board, in Mumbai, Maharashtra. The Explorer 16/32 Development Board is intended as a development, demonstration, and testing platform for many families of Microchip 16-bit and 32-bit microcontroller devices. Add a header file called "BoardConfig.h" to the "header files" section.Create a new standalone project in MPLABx for PIC16F877A using the lastest XC8 compiler and name the project as per the example you want to use e.g.To use any of the code, all you have to do is the following To ensure they work OK with the MPLAB X IDE and the XC8 complier, I have recoded the examples and listed them in folder "CODE". When you buy this board the supplied CD contains example code but it is quite old. This repository is for collecting the programs that can be used with the BK300 Pic Development board as seen in the picture above. BK300-Pic16f877A-development-Board-Examples
